Generic Electric Toothbrush User Manual

1. Муқаддима

Thank you for choosing the Generic Electric Toothbrush. This manual provides essential information for the safe and effective use of your new electric toothbrush. Please read it thoroughly before first use and keep it for future reference. This toothbrush is designed to provide a deep and effective clean, promoting better oral hygiene.

2. Маълумот оид ба бехатарӣ

• Do not use this product for any purpose other than oral cleaning.
• Keep the toothbrush out of reach of small children.
• Consult a dentist before use if you have severe gum disease, oral surgery, or other oral health concerns.
• Do not immerse the charging base in water. The toothbrush handle is IPX7 waterproof, but the charging base is not.
• Do not attempt to disassemble or repair the toothbrush yourself. Contact customer support for assistance.
• Ensure the USB-C charging port cover is securely closed before exposing the toothbrush to water.

3. Мундариҷаи баста

Лутфан тафтиш кунед, ки ҳама ашё дар бастаи шумо мавҷуданд:

• 1 x Дастаки дандоншуии барқӣ
• 4 x Replacement Brush Heads
• 1 x USB-C Charging Cable (Charger not included, use a standard USB power adapter)

Figure 1: Package contents including the toothbrush handle, four brush heads, and charging cable.

4. Маҳсулот ба охир расидview

The Generic Electric Toothbrush is designed for effective oral cleaning with advanced sonic technology. It features multiple brushing modes, a smart timer, and a long-lasting rechargeable battery.

Расми 2: Зиёдview of the electric toothbrush design.

Хусусиятҳои асосӣ:

• High-Frequency Vibrations: Up to 40,000 vibrations per minute for effective plaque removal.
• 8 Усулҳои тозакунӣ: Customizable cleaning experience for various oral care needs.
• Вақтсанҷи оқил: Built-in 2-minute timer with 30-second interval reminders.
• Ҳаёти батареяи дароз: Up to 120 days of use on a single 2.5-hour charge.
• IPX7 обногузар: Allows for safe use in the shower or bath.
• Пуркунии USB-C: Қулай ва тез қувватлаш.

5. Танзимот

5.1 Пуркунии ибтидоӣ

Before first use, fully charge the toothbrush for approximately 3 hours to activate the battery. The battery indicator light will show charging status.

1. Open the waterproof cover at the bottom of the toothbrush handle.
2. Insert the USB-C charging cable into the port.
3. Connect the other end of the USB-C cable to a standard USB power adapter (not included) and plug it into a power outlet.
4. Once charging is complete, remove the cable and securely close the waterproof cover.

Figure 3: Charging the electric toothbrush via USB-C.

5.2 Пайваст кардани сари хасу

Сари хасуро бо мехи металлии дастаки хасуи дандон ҳамвор кунед ва онро сахт пахш кунед, то он даме ки ба ҷои худаш лағжад. Пеш аз истифода боварӣ ҳосил кунед, ки он боэътимод васл шудааст.

6. Дастурҳои истифодабарӣ

6.1 Фаъолсозӣ/хомӯшкунӣ ва интихоби режим

1. Press the power button once to turn on the toothbrush. It will start in the last used mode.
2. Press the power button repeatedly to cycle through the 8 available modes.
3. To turn off the toothbrush, press and hold the power button for 2 seconds, or cycle through all modes until it turns off automatically.

Figure 4: The 8 brushing modes and their LED indicators.

6.2 Усулҳои тозакунӣ

The toothbrush offers 8 distinct modes to cater to various oral care needs:

• Сафед: Inverted frequency for gum care.
• Тоза: Gentle frequency for sensitive gums.
• Nurse: Standard daily teeth cleaning.
• Нигоҳубин: Improves gum health by delivering soothing vibrations into tissue.
• нарм: Low frequency for soft cleaning.
• Лаҳистон: Super-strong frequency to eliminate stubborn stains.
• Набз: For massage and protecting gums.
• Равшанӣ: Deep whitening teeth.

6.3 Усули шустушӯи дандонҳо ва таймери интеллектуалӣ

Apply a small amount of toothpaste to the brush head. Place the brush head against your teeth at a slight angle towards the gumline. Gently move the brush across your teeth, allowing the sonic vibrations to do the work. Do not scrub vigorously.

The built-in smart timer will automatically turn off the toothbrush after 2 minutes, which is the dentist-recommended brushing time. Additionally, it will pause briefly every 30 seconds to remind you to move to a different quadrant of your mouth, ensuring a thorough and even clean.

Figure 5: Intelligent reminder for 2-minute brushing with 30-second intervals.

7. Тозакунӣ ва нигоҳдорӣ

7.1 Тоза кардани хасуи дандон

1. Пас аз ҳар истифода, сари хасуро дар зери оби равон бодиққат бишӯед.
2. Дастаки чуткаи дандоншуйро бо реклама тоза кунедamp матоъ. Тозакунакҳои абразивӣ ё кимиёвии сахтро истифода набаред.
3. Ensure the USB-C charging port cover is always closed when not charging to maintain its IPX7 waterproof rating.

Figure 6: The toothbrush features an IPX7 waterproof design.

7.2 Иваз кардани саракҳои хасу

Dentists recommend replacing brush heads every 3 months, or sooner if the bristles become frayed. To replace:

1. Pull the old brush head straight off the handle.
2. Сари нави хасуро бо мехи металлӣ ҳамвор кунед ва онро сахт пахш кунед, то он даме ки он ба ҷои худ ҷойгир шавад.

7.3 Нигоҳдорӣ

Store the toothbrush in a cool, dry place when not in use. Ensure it is clean and dry before storing.

8. Баррасии мушкилот

9. Мушаххасоти

10. Кафолат ва дастгирӣ

Барои маълумоти кафолат ва дастгирии муштариён, лутфан ба ҳуҷҷатҳои ҳангоми харид пешниҳодшуда муроҷиат кунед ё бо фурӯшандаи худ тамос гиред. Барои ҳама даъвоҳои кафолат далели хариди худро нигоҳ доред.
