Дастури корбарии телефони мизи Polycom VVX 250 IP

Маҳсулот ба охир расидview

The Polycom VVX 250 is a four-line, basic IP desk phone featuring a color display, designed for clear and efficient communication.

Хусусиятҳои асосӣ:

• Make more natural and life-like calls with Polycom HD Voice
• 2.8” color display: an engaging experience offering visual information at a glance
• Two Gigabit Ethernet ports offer cost savings and performance benefits
• USB port enables users to move data around more quickly
• Integrates with more than 60 industry leading call control platforms

Пеш view of the Polycom VVX 250 IP Desk Phone, showcasing its handset, keypad, and color display.

Дастури насб

Follow these steps to set up your Polycom VVX 250 IP Desk Phone.

Мундариҷаи баста:

• Polycom VVX 250 IP Desk Phone unit
• Handset and coiled cord
• Сими Ethernet
• Истгоҳи стол
• (Note: Power adapter may be sold separately depending on model/region.)

Пайвастҳои ҷисмонӣ:

1. Гӯшмонакро пайваст кунед: Plug one end of the coiled cord into the handset and the other end into the handset port on the phone base.
2. Пайвастшавӣ ба шабака: Connect an Ethernet cable from your network switch or router to the LAN port (marked with a network icon) on the back of the phone.
3. Пайваст кардани барқ: If not using Power over Ethernet (PoE), connect the power adapter (if included) to the power port on the back of the phone and plug it into a power outlet.
4. Connect to PC (Optional): If you wish to connect a computer through the phone, connect an Ethernet cable from your computer to the PC port (marked with a computer icon) on the back of the phone.
5. Гӯшмонакро пайваст кунед (ихтиёрӣ): Plug your compatible headset into the headset port (marked with a headset icon) on the back of the phone.

Аз наздики view of the back of the Polycom VVX 250 IP Desk Phone, showing the Ethernet (LAN and PC), power, and headset ports.

Боркунии ибтидоӣ:

Once connected, the phone will power on and begin its boot-up sequence. This may take a few minutes. The display will show the Polycom logo and then proceed to load its firmware and configuration.

If your network supports automatic provisioning, the phone will automatically configure itself. Otherwise, you may need to manually enter network settings or contact your VoIP service provider for assistance.

Дастурҳои амалиётӣ

Занг задан:

1. Pick up the handset, press the Speakerphone button, or press a line key.
2. Бо истифода аз клавиатура рақами дилхоҳро занг занед.
3. Press the Dial soft key or wait for the call to connect automatically.

Ҷавоб додан ба занг:

When the phone rings, pick up the handset, press the Speakerphone button, or press the flashing line key.

Using the Display and Menu:

The 2.8-inch color display provides access to various phone functions and settings.

• -ро истифода баред Кластери навигатсионӣ (up, down, left, right arrows, and Select button) to browse through menus and options.
• -ро пахш кунед Хона button to return to the main menu or idle screen.
• Тугмаҳои нармафзор: The buttons directly below the display change their function based on the current screen or activity.

Функсияҳои умумӣ:

• Нигоҳ доред: Press the Hold button during an active call to place it on hold. Press again to resume.
• Интиқол: During an active call, press the Transfer button, dial the new number, and then press Transfer again to complete.
• Хомӯш кардан: Press the Mute button to mute your microphone during a call. Press again to unmute.
• Баландгӯяк: Press the Speakerphone button to toggle speakerphone mode on or off.
• Гӯшмонак: Press the Headset button to switch audio to a connected headset.
• Назорати овоз: -ро истифода баред + ва - buttons below the keypad to adjust handset, headset, or speakerphone volume.

A person is shown using the Polycom VVX 250 IP Desk Phone at a desk, demonstrating its use in a typical office environment.

Дастрасӣ ба менюҳо:

Аз экрани бекор, -ро пахш кунед Хона button to access the main menu. Options typically include:

• Занги нав
• Messages (Voicemail)
• Directories (Contact lists)
• DND (Хароҷ нашавед)
• Settings (Phone configuration)
• Applications (if configured)

An official video demonstrating the key features of the Polycom VVX 250, including HD audio, 2.8-inch color LCD screen, and 4 line keys.

Нигоҳдорӣ

To ensure optimal performance and longevity of your Polycom VVX 250 IP Desk Phone, follow these maintenance guidelines:

• Тозакунӣ: Use a soft, dry, lint-free cloth to clean the phone's surface and display. Avoid abrasive cleaners, solvents, or aerosol sprays.
• Тоза кардани чанг: Regularly dust the keypad and speaker grilles to prevent accumulation that could affect performance.
• Идоракунии кабелӣ: Ensure all cables are securely connected and not under strain. Avoid sharp bends or kinks in the cords.
• Шароити экологӣ: Operate the phone within recommended temperature and humidity ranges. Avoid direct sunlight, excessive heat, or moisture.
• Навсозии нармафзор: Periodically check with your service provider for available firmware updates to ensure your phone has the latest features and security enhancements.

Мушкилкушо

This section provides solutions to common issues you might encounter with your Polycom VVX 250 IP Desk Phone.

Оҳанги занг задан нест/Занг задан мумкин нест:

• Пайвасти шабакаро тафтиш кунед: Ensure the Ethernet cable is securely plugged into both the phone's LAN port and the network jack/router.
• Сикли барқ: Unplug the phone's power adapter (or Ethernet cable if using PoE), wait 10 seconds, then plug it back in.
• Verify Network Status: Check if other devices on your network are functioning correctly.
• Contact Service Provider: If the issue persists, your VoIP service may be down or require re-provisioning.

Сифати аудио:

• Танзими овоз: Use the volume buttons on the phone to increase or decrease the call volume.
• Check Handset/Headset Connection: Ensure the handset or headset cord is securely connected.
• Қатъи шабака: High network traffic can affect call quality. Try reducing network usage or contact your IT administrator.
• Овози HD: Ensure both parties are using HD Voice compatible devices and network for optimal clarity.

Намоиш кор намекунад:

• Санҷиши нерӯ: Ensure the phone is receiving power.
• Сикли барқ: Perform a power cycle as described above.
• Танзимоти равшанӣ: Navigate to Settings > Basic > Display > Backlight Intensity to adjust brightness.

Phone Not Registering:

• Пайвастшавӣ ба шабака: Confirm the phone has an active network connection.
• Конфигуратсия: Verify that the phone's configuration settings (SIP server, user credentials) are correct. This usually requires IT or service provider assistance.
• Нармафзори миёнаравӣ: Outdated firmware can sometimes cause registration issues.

Мушаххасоти

Дар қуттӣ чӣ ҳаст

The standard package for the Polycom VVX 250 IP Desk Phone typically includes:

• Polycom VVX 250 IP Desk Phone Unit
• Дастгоҳи телефонӣ
• Сими дастӣ
• Сими шабакавӣ (Ethernet)
• Истгоҳи мизи корӣ
• Дастури оғози зуд

Note: Power adapter may be sold separately depending on the specific product variant or region.

Кафолат ва дастгирӣ

Маълумот дар бораи кафолат:

Poly products typically come with a limited hardware warranty. Please refer to the warranty card included with your product or visit the official Poly website for detailed warranty terms and conditions specific to the VVX 250 model. Retain your proof of purchase for warranty claims.

Пуштибонии фаннӣ:

For technical assistance, troubleshooting, or further inquiries, please contact Poly customer support.

• Дастгирии онлайн: Visit the Poly support website for FAQs, knowledge base articles, and software downloads.
• Дастгирии телефон: Contact your regional Poly support hotline.
• Таъминкунандаи хидмат: If your phone was provided by a VoIP service provider, they may be your primary point of contact for support and configuration.

Always provide your product model (VVX 250) and serial number when contacting support for faster service.
