Дастури корбарии 10-дюймаи аксбардории рақамии KODAK WiFi

1. Муқаддима

This manual provides detailed instructions for the setup, operation, and maintenance of your KODAK WiFi Digital Photo Frame. Please read this manual thoroughly before using the product to ensure proper functionality and to maximize your user experience. Keep this manual for future reference.

2. Маҳсулот ба охир расидview

2.1 Хусусиятҳои асосӣ

• Намоиши баландсифат: 10.1-inch IPS touch panel with 1280x800 resolution and a 178-degree wide viewкунҷи дохилӣ.
• Пайвастшавӣ Wi-Fi: Share photos and videos in real-time from your smartphone or tablet using the dedicated app.
• Захираи дохилӣ: 16 ГБ хотираи дарунсохт.
• Дастгирии нигаҳдории беруна: Compatible with SD/MMC cards and USB memory devices up to 32GB.
• Бисёрфунксионалӣ: Includes calendar, time display, alarm clock, weather forecast, and music playback features.
• Photo Management: Supports photo trimming and rotation directly on the frame.

2.2 Мундариҷаи баста

Боварӣ ҳосил кунед, ки ҳама ашё дар баста мавҷуд аст:

• KODAK WiFi Digital Photo Frame
• Power Adapter (PSE certified)
• Сими USB сими
• Дастури корбар

Image: Contents of the KODAK WiFi Digital Photo Frame package.

2.3 Муайянкунии ҷузъҳо

Familiarize yourself with the ports and buttons on your photo frame:

• MMC/SD Card Jack: For inserting SD or MMC memory cards (up to 32GB).
• 3.5 мм Jack гӯшмонак: Барои пайваст кардани дастгоҳҳои аудиоии беруна.
• Порти USB: For connecting USB memory devices (up to 32GB).
• Порти хурди USB: For connecting the frame to a computer to transfer data.
• Пайвасткунандаи барқ: Барои пайваст кардани адаптери барқ.
• Тугмаи барқ: Барои фурӯзон/хомӯш кардани дастгоҳ.
• Тугмаҳои баландии овоз (+/-): To adjust audio volume.
• Маърузачиён: Integrated speakers for audio playback.
• Истгоҳ: Adjustable stand for positioning the frame.

Тасвир: Қафо ва паҳлӯ view of the photo frame highlighting various ports and controls.

3. Танзимот

3.1 Пайвастшавии барқ

1. Connect the power adapter to the Power Connector on the frame.
2. Адаптери барқро ба васлаки деворӣ пайваст кунед.
3. Press the Power Button to turn on the frame.

Муҳим: Ensure the power plug is fully inserted. Partial insertion may prevent the device from powering on.

3.2 Танзимоти Wi-Fi

The frame supports Танҳо шабакаҳои Wi-Fi 2.4 ГГц. If you are using a 5GHz network, you must switch to a 2.4GHz network for connection.

1. On the frame's main screen, navigate to "Settings" and then "Wi-Fi".
2. Select your 2.4GHz Wi-Fi network from the list.
3. Бо истифода аз клавиатураи экран пароли Wi-Fi-ро ворид кунед.
4. Пайвастшавиро тасдиқ кунед.

3.3 App Installation and Frame Pairing

To share photos and videos wirelessly, install the dedicated "KODAK Classic Frame" app on your smartphone or tablet (iOS/Android compatible).

1. Барномаро насб кунед:
   • Ҷустуҷӯ "KODAK Classic Frame" in the App Store (iOS) or Google Play (Android) and download it.
   • Alternatively, on the frame, go to "Settings" → "User" → "APP Download Method" to scan the QR code for direct download.
2. Ҳисобро ба қайд гиред:
   • Open the app and register using your email address.
   • Рамзи тасдиқи ба почтаи электронии шумо фиристодашударо ворид кунед.
   • Set a password and enter a nickname.

   Note: Verification emails may be in English/Chinese. The code is typically a sequence of English characters at the end of the email.

3. Add the Photo Frame:
   • On the frame, go to "Settings" → "User" to display the QR code. Scan this QR code with the app.
   • Alternatively, manually enter the 9-digit code displayed on the frame's "User" screen into the app.

Image: Visual guide for installing the KODAK Classic Frame app and connecting it to the digital photo frame.

4. Дастурҳои истифодабарӣ

4.1 Uploading Photos and Videos

Once the frame is paired with the app, you can upload media:

• Open the "KODAK Classic Frame" app on your smartphone/tablet.
• Select the photos or videos you wish to upload.
• Choose the target photo frame and initiate the upload.
• Alternatively, you can take photos directly from the app and upload them.

Шарҳ: There are no regional restrictions for sharing content via Wi-Fi.

Image: Illustration of multiple users sharing images to the digital photo frame via Wi-Fi.

4.2 Using SD Card / USB Memory

Insert an SD/MMC card or USB memory stick (up to 32GB) into the corresponding slot on the frame. The frame will automatically detect the storage and allow you to browse and play media.

Барои интиқол files from a computer, connect the frame via the mini USB cable. The frame will appear as a removable drive, allowing you to drag and drop files to its internal memory.

4.3 Photo Management (Trimming & Rotation)

Кай viewing a single photo, tap the screen to reveal options. You can then select "Rotate" to adjust the photo's orientation or "Trim" to crop the image.

Image: Display showing photo trimming and rotation functions available on the frame.

4.4 Хусусиятҳои бисёрфунксионалӣ

Your photo frame includes several utility functions:

• Тақвим: Access the calendar from the main menu.
• Clock & Alarm: Set alarms and view вақти ҷорӣ.
• Обу ҳаво: Display local weather information. Tap the magnifying glass icon on the weather screen and enter your city name to update the forecast.
• Бозии мусиқӣ: Навозиши аудио files stored on the frame or connected storage.

Image: The frame displaying calendar, clock, and alarm features.

4.5 Screen Saver Settings

You can change the screen saver type and duration. Go to "Settings" → "User Settings" to adjust screen saver time and type (e.g., clock display).

4.6 Vertical Display

If you rotate the frame vertically, photos will display vertically from the next image in a slideshow or when playing all media. For a single photo, tap the screen and use the "Rotate" option to adjust its orientation.

5. Нигоҳдорӣ

To ensure the longevity and optimal performance of your KODAK WiFi Digital Photo Frame, follow these maintenance guidelines:

• Тозакунӣ: Use a soft, dry, lint-free cloth to clean the screen and exterior. Do not use liquid cleaners or abrasive materials.
• Нигоҳдорӣ: Вақте ки дар муддати тӯлонӣ истифода набаред, чаҳорчӯбаро дар ҷои хунук ва хушк дур аз нурҳои бевоситаи офтоб ва ҳарорати аз ҳад зиёд нигоҳ доред.
• Муносибат: Дастгоҳро партофтан ё ба таъсири сахт дучор нашавед.
• Вентилятсия: Ensure the ventilation holes on the back of the frame are not blocked to prevent overheating.

6. Баррасии мушкилот

This section addresses common issues you might encounter with your photo frame.

6.1 Масъалаҳои барқ

Мушкилот: The frame does not turn on when the power button is pressed.

Ҳалли: Ensure the power adapter is fully and securely plugged into both the frame's power connector and the wall outlet. A loose connection is a common cause.

6.2 Масъалаҳои пайвасти Wi-Fi

Мушкилот: Unable to set up Wi-Fi.

Ҳалли: Ин маҳсулот танҳо дастгирӣ мекунад 2.4GHz Wi-Fi bands. If your router uses a 5GHz band, you must switch to the 2.4GHz band for the frame to connect.

6.3 Input Method Issues

Мушкилот: Cannot input Japanese characters (Kanji/Kana) or find the conversion key.

Ҳалли:

1. Long-press the "Aa" key on the 12-key keyboard.
2. Go to "Language: Japanese (12-key)" → "Add Keyboard" → "Japanese" → "QWERTY (26-key)" → "Done".

After this, you can input Kanji and Kana using the 26-key QWERTY keyboard. The 26-key keyboard is recommended for easier text input.

6.4 SD Card Issues

Мушкилот: SD card cannot be inserted.

Ҳалли: Check the insertion direction. Ensure the side with text is facing outwards and align it correctly before inserting. Do not force the card.

Мушкилот: SD card is inserted but not recognized.

Ҳалли:

• The product supports SD cards up to a maximum of 32GB. Ensure your card is within this limit.
• Ensure the SD card is inserted about halfway into the slot.
• Try removing and reinserting the SD card.
• Restart the photo frame.

6.5 Weather Display Issues

Мушкилот: Weather forecast is not displayed, or temperature shows "N/A" despite Wi-Fi being connected.

Ҳалли: On the weather forecast screen, tap the magnifying glass icon and enter your city name in the search bar to update the weather information.

7. Мушаххасоти

8. Кафолат ва дастгирӣ

8.1 Quality Guarantee

Your KODAK WiFi Digital Photo Frame comes with a Кафолати 1 сол сифат. KODAK is a professional in the imaging industry.

8.2 Тамос бо дастгирии

If you receive a product different from your order, experience initial defects (damage, missing parts), or encounter quality issues during normal use, please contact the seller directly through Amazon:

1. Go to "Account Service".
2. Select "Order History".
3. Find your order and click on the "Seller".
4. Click "Ask a question" to send an email to the seller.

The seller aims to respond within 24 hours.
