Дастури корбарии мошини эспрессо барои Solis Grind & Infuse Perfetta 1019

1. Муқаддима

This manual provides detailed instructions for the safe and efficient operation, maintenance, and care of your Solis Grind & Infuse Perfetta 1019 Espresso Machine. Please read all instructions carefully before first use and retain this manual for future reference.

Тасвири 1.1: Пеш view of the Solis Grind & Infuse Perfetta 1019 Espresso Machine. The machine features a stainless steel finish, an integrated bean hopper on top, control buttons, a pressure gauge, a digital display, a portafilter, and a steam wand.

2. Кушодан ва насби ибтидоӣ

2.1 Унсурҳои дохилшуда

Боварӣ ҳосил кунед, ки ҳама ҷузъҳо дар бастабандӣ мавҷуданд:

• Solis Grind & Infuse Perfetta 1019 Espresso Machine
• Портафилтр
• Filter inserts for 1 and 2 cups
• Water tank including BRITA water filter
• Milk pitcher (350 ml)
• Пӯлоди зангногир тamper
• Rubber insert for cleaning the brew head
• Water test strip

Тасвири 2.1: Ба охир расидview of the Solis Grind & Infuse Perfetta 1019 Espresso Machine with its dimensions and included accessories. Accessories shown include the tamper, milk pitcher, various filter inserts, and a BRITA water filter.

2.2 Ҷойгиркунӣ ва пайвасти барқ

1. Place the machine on a stable, level, and heat-resistant surface. Ensure adequate ventilation around the unit.
2. Connect the power cord to a grounded electrical outlet (230V AC).

2.3 Насби зарфи об ва филтр

1. Зарфи обро аз қафои мошин хориҷ кунед.
2. Install the provided BRITA Intenza water filter into the water tank according to the filter's instructions.
3. Fill the water tank with fresh, cold water up to the MAX level indicator.
4. Зарфҳои обро ба мошин бехатар гузоред.

Image 2.2: A hand removing the water tank from the rear of the espresso machine, showing the integrated BRITA water filter.

2.4 Bean Hopper Installation

1. Place the bean hopper onto the top of the machine, ensuring it is correctly seated.
2. Fill the bean hopper with fresh whole coffee beans. The hopper has a capacity of 200 grams.

3. Амалиёт

3.1 Қаҳваи қаҳва

The integrated Zero Static coffee grinder offers 25 different grind settings for optimal extraction.

1. Select the desired grind setting using the adjustment lever next to the bean hopper. A finer grind is typically used for espresso.
2. Place the portafilter under the grinder outlet.
3. Use the digital micro-timer to set the grinding duration. The display shows the grind time.
4. Initiate grinding by pressing the grind button or by pushing the portafilter against the activation switch.
5. Баъди суфта кардан, тamp the coffee grounds evenly and firmly using the provided tampэ.

Тасвири 3.1: Наздик view of freshly ground coffee being dispensed into the portafilter from the integrated grinder.

3.2 Истеҳсоли эспрессо

The machine features an adaptive PID controller for precise water temperature stabilization and a manometer to monitor brewing pressure.

1. Insert the prepared portafilter into the brew group and turn it to lock it securely in place.
2. Пиёлаҳоятонро дар зери лӯлаҳои филтри портафилтр ҷойгир кунед.
3. Select either a single or double shot using the dedicated buttons. The brew time can be programmed to your preference.
4. Monitor the manometer during brewing. The ideal pressure for espresso extraction is between 8 and 12 bar.
5. The digital display will show the brewing duration.

Image 3.2: The Solis Perfetta machine actively brewing espresso into a glass cup. The manometer on the front panel indicates the brewing pressure.

3.3 Steam and Hot Water Function

The machine is equipped with a steam wand for frothing milk and a hot water function for other beverages.

1. To froth milk, fill the milk pitcher with cold milk.
2. Position the steam wand into the milk and activate the steam function. Move the pitcher to create desired milk foam texture.
3. To dispense hot water, activate the hot water function and place a cup under the hot water spout.

Image 3.3: A person using the steam wand of the Solis Perfetta to froth milk in a stainless steel pitcher, preparing for latte art.

4. Нигоҳдорӣ ва тозакунӣ

Тозакунии мунтазам кори беҳтарин ва мӯҳлати кори мошини эспрессои шуморо таъмин мекунад.

4.1 Тозакунии ҳаррӯза

• Empty and clean the drip tray and grid after each use.
• Rinse the portafilter and filter basket under running water.
• Purge the steam wand after each use to prevent milk residue buildup. Wipe it with a damp матоъ.

4.2 Cleaning the Brew Head

Use the provided rubber insert for backflushing the brew head.

1. Insert the rubber cleaning disc into the portafilter basket.
2. Lock the portafilter into the brew group.
3. Activate the brewing cycle for a few seconds, then stop. Repeat several times to flush out coffee residues.

4.3 Иваз кардани филтри об

Replace the BRITA Intenza water filter regularly as indicated by the filter's instructions or the machine's prompts to maintain water quality and prevent scale buildup.

5. Баррасии мушкилот

Ин бахш мушкилоти умумиеро, ки шумо метавонед дучор ояд, баррасӣ мекунад.

6. Мушаххасоти техникӣ

7. Кафолат ва дастгирӣ

For warranty information, technical support, or service inquiries, please contact Solis customer service. Keep your proof of purchase for any warranty claims.

Solis of Switzerland is committed to providing excellent customer support.
