1. Муқаддима
Thank you for choosing the ALLWEI Portable Power Station. This manual provides essential information for the safe and efficient operation of your device. Please read it thoroughly before use and retain it for future reference.
Мундариҷаи баста:
- 1x ALLWEI 300W/256Wh Portable Power Station
- 1x кабели AC
- 1x DC Car Cable
- 1x Дастури корбар
Note: ALLWEI Solar Panel sold separately.
2. Дастурамал оид ба бехатарӣ
To ensure safe operation and prolong the lifespan of your power station, please adhere to the following guidelines:
- Дастгоҳро ҷудо накунед, таъмир накунед ё тағир надиҳед.
- Дастгоҳро аз манбаъҳои гармӣ, нури бевоситаи офтоб ва маводи сӯхташаванда дур нигоҳ доред.
- Аз таъсири об ё намии баланд пешгирӣ кунед.
- Use only original or certified cables and adapters for charging.
- Ҳангоми истифода ва пуркунии барқ вентилятсияи дурустро таъмин кунед.
- The advanced Battery Management System (BMS) provides 6-layer protection against short-circuit, over-current, over-voltagд, ва ғайра.
3. Маҳсулот ба охир расидview
The ALLWEI Portable Power Station is designed for versatility and ease of use, featuring multiple output ports and a clear display.
Ports and Display:
- Нуқтаҳои AC: 1x 110V/300W Max (Pure Sine Wave)
- Натиҷаҳои DC: 2x DC5521 ports (12V/3A), 1x Car Cigarette Lighter Port (DC12V/8A)
- Портҳои USB: 1x USB-A Fast Charge (18W), 1x USB-C PD (60W)
- Намоиш: Дараҷаи батарея, ВТ вуруд / баромадро нишон медиҳадtagд, ва вақти боқимондаи иҷрои тахминӣ.
- Нури LED: 3-level adjustable LED light with SOS mode.
4. Танзимот
Пуркунии ибтидоӣ:
Before first use, fully charge your ALLWEI Portable Power Station. Use the provided AC cable to connect the unit to a wall outlet. The display will indicate charging status. A full charge typically takes 3.5-4 hours via AC wall charging.
5. Дастурҳои истифодабарӣ
Powering On/Off Outputs:
- To activate AC outputs, press the 'AC' button.
- To activate DC outputs (including car port), press the 'DC' button.
- To activate USB outputs, press the 'USB' button.
- Press the respective button again to turn off the outputs.
Истифодаи нури LED:
Press the 'LED' button to turn on the light. Subsequent presses will cycle through 3 brightness levels and an SOS flashing mode. Press and hold to turn off.
Пуркунии ҳамзамон:
The power station can charge up to 6 devices simultaneously. The display will update to show the combined output wattagд ва вақти тахминии боқимондаи кор.
Видеоҳои расмии маҳсулот:
Видео 1: Намоишasing Allwei Portable Power Station. This video provides a general overview and demonstration of the ALLWEI Portable Power Station's features and functionality.
Video 2: Allwei for the win! This short video highlights the convenience and reliability of the ALLWEI Portable Power Station in various scenarios.
6. Пур кардани нерӯгоҳи барқӣ
The ALLWEI Portable Power Station offers multiple flexible recharging options:
- Пуркунии девори AC: Fully recharges in 3.5-4 hours using the provided AC cable.
- Пуркунии мошин 12V: Fully recharges in 3.5-4 hours using the provided DC car cable.
- Пуркунии панели офтобӣ: Fully recharges in 4-5 hours with a 100W solar panel (sold separately). The built-in MPPT controller optimizes solar charging efficiency.
- Пуркунии дугона (AC + офтобӣ): Achieve a full recharge in just 2-2.5 hours by combining AC wall charging and solar panel input.
7. Нигоҳдорӣ
Нигоҳдорӣ:
Store the power station in a cool, dry place away from direct sunlight and extreme temperatures. For optimal battery health, recharge the unit every 3-6 months, even if not in use, to maintain a charge level above 50%.
Тозакунӣ:
Wipe the exterior of the power station with a soft, dry cloth. Do not use abrasive cleaners or immerse the unit in water.
8. Баррасии мушкилот
If you encounter issues with your ALLWEI Portable Power Station, please refer to the following common solutions:
- Дастгоҳ пур карда намешавад: Ensure the power station is sufficiently charged and the output port is activated. Check the connection cable for damage.
- Power station not charging: Verify that the charging cable is securely connected to both the power station and the power source. Try a different outlet or charging method.
- Намоиш кор намекунад: Ensure the power station is turned on. If the issue persists, contact customer support.
For more complex issues or persistent problems, please contact ALLWEI customer service.
9. Мушаххасоти
| Хусусият | Тафсилот |
|---|---|
| Бренд | ALLWEI |
| Номи модел | Станцияи электрикии сайёр |
| Рақами модели ашё | PPS300-4 |
| Ватtage | 300 watts (Running), 600 watts (Peak) |
| Иқтидори батарея | 256Wh LiFePO4 |
| Давраҳои батарея | 3000+ (approx. 10-year lifespan) |
| Портҳои баромад | 1x AC, 2x DC5521, 1x Car Port, 1x USB-A (18W), 1x USB-C (60W) |
| Натиҷаи AC Voltage | 110 вольт |
| Усулҳои пуркунии барқ | AC Wall, 12V Car, Solar Panel, Dual (AC+Solar) |
| Вақти пуркунии AC | 3.5-4 соат |
| Solar Charging Time (100W) | 4-5 соат |
| Dual Charging Time (AC+Solar) | 2-2.5 соат |
| Вазни ашё | 6.4 фунт |
| Андозаҳои маҳсулот | 9.25"L x 5"W x 6.8"H |
| Хусусиятҳои махсус | LiFePO4, Pure Sine Wave, MPPT Controller, 3-level LED light with SOS mode, BMS Protection |
| Материал | ABS |
| UPC | 732133487990 |
10. Кафолат ва дастгирӣ
ALLWEI stands behind the quality of its products. Your Portable Power Station is covered by a comprehensive warranty and dedicated customer support.
- Кафолат: Кафолати 5 сол.
- Хидмат ба муштари: 7x24 customer service is available to assist you with any questions or concerns.
- Бозгашт: Enjoy a 30-day no-hassle return policy.
Барои кӯмак лутфан ба мо дар тамос шавед: support@allweipower.com
