Дастури корбарии муши амудии бесими эргономикии Acer OCC314

1. Муқаддима

Thank you for choosing the acer Ergonomic Wireless Vertical Mouse OCC314. This manual provides essential information for setting up, operating, and maintaining your new mouse. Designed for comfort and efficiency, this vertical mouse helps reduce wrist and arm strain during extended use.

Figure 1: acer Ergonomic Wireless Vertical Mouse OCC314

2. Хусусиятҳои асосӣ

• 58° Ergonomic Vertical Design: Naturally contours to your right hand, reducing wrist and arm pressure.
• Пайвасти бесими 2.4 ГГц: Provides a fast and stable connection via the included USB-A receiver with a reliable range of up to 10 meters. (Note: This is NOT a Bluetooth connection.)
• Батареяи пуриқтидори пурқувват: Equipped with a 500mAh rechargeable battery for long-term convenience. Charges via USB-C.
• 3 DPI Settings: Customizable DPI levels (800/1200/1600) for optimal precision. An intuitive visual indicator flashes to confirm your selected DPI setting.
• Quick Navigation Side Buttons: Dedicated forward and backward buttons for rapid browsing and folder navigation. (Note: Side buttons do not work on Mac operating systems.)
• Функсияи худкори хоб: Enters sleep mode after 10 minutes of inactivity to conserve battery. Wake with a double click.

Figure 2: 58° Ergonomic Vertical Design for reduced wrist pressure.

Figure 3: Adjustable DPI settings for precision control.

3. Дастурамал оид ба насб

1. Қабулкунаки USB-ро пайдо кунед: The USB-A receiver is stored inside the mouse, accessible by removing the small cover on the bottom.
2. Қабулкунандаро пайваст кунед: Plug the USB-A receiver into an available USB-A port on your computer (laptop, PC, or desktop).
3. Фаъол кардани муш: Бо истифода аз тугмаи барқ, ки дар поён ҷойгир аст, мушро фаъол созед.
4. Пайвасти худкор: The mouse should automatically connect to your computer. No additional drivers are typically required for plug-and-play functionality.

Figure 4: Visual guide for initial setup.

4. Дастурҳои истифодабарӣ

4.1 Hand Position

Rest your palm naturally against the mouse's contour. The 58° vertical tilt is designed to align your wrist in a more natural handshake position, reducing strain.

4.2 Adjusting DPI

Press the DPI button (located near the scroll wheel) to cycle through the 800, 1200, and 1600 DPI settings. The indicator light will flash to confirm the selected setting.

4.3 Using Side Buttons

Use the dedicated forward and backward buttons on the side of the mouse for quick navigation in web браузерҳо ва file кашфкунандагон. (Note: These buttons are not functional on Mac operating systems.)

Figure 5: Side buttons for efficient navigation.

5. Нигоҳдорӣ

5.1 Пур кардани муш

When the indicator light flashes rapidly, it signifies a low battery. Connect the included USB-C cable to the charging port on the front of the mouse and to a USB power source. A full charge takes approximately 90 minutes.

5.2 Тозакунӣ

To clean the mouse, use a soft, dry cloth. Avoid using harsh chemicals or abrasive materials that could damage the surface.

6. Баррасии мушкилот

• Mouse Malfunction/Re-pairing: If the mouse malfunctions or loses connection, press and hold the Left Button, Right Button, and Scroll Wheel simultaneously for a few seconds to re-pair it with the USB receiver.
• Side Buttons on Mac: The forward and backward side buttons are not supported on Mac operating systems. This is a design limitation.
• Mouse Not Waking Up: If the mouse is in auto-sleep mode, double-click any button to wake it up. Ensure the battery is charged.
• Масъалаҳои пайвастшавӣ: Ensure the USB-A receiver is securely plugged into a working USB port. Try a different USB port if necessary.

7. Мушаххасоти

Расми 6: Зиёдview of mouse buttons and components.

8. Кафолат ва дастгирӣ

For warranty information and customer support, please refer to the documentation included with your product or visit the official acer support webсайт. Квитансияи хариди худро барои даъвоҳои кафолат нигоҳ доред.
